Exitex Silver Lowline 914mm Macclex Sill
Pack of 1
Exitex Macclex Lowline Sill - Silver - 914mm
For inward opening doors, under door clearance 20mm, suitable for exposed locations
For inward opening doors, under door clearance 20mm, suitable for exposed locations
£20.77
£17.31
Availablity: In stock
SKU
41122
Exitex Macclex Lowline Sill
Colour : Silver
Size : 914mm
Product Information
- For inward opening doors
- Under door clearance20mm
- Suitable for exposed locations
- Ideal for double doors
- Accepts standard striker block
Fitting Instructions
- Remove rubber seal from Aluminium sill section. Check width between outside faces of the doorframe rebate and cut aluminium section to this size.
- Cut the rubber seal to 12mm longer than aluminium section to allow seal to extend into the kwikfit lugs and re-insert into the groove in sill. Attach kwikfit lugs to each end of the sill.
- This sill requires an under door clearance of 20mm. If necessary, remove door and trim to allow for this, ensuring bottom of door is smooth to avoid damage to rubber seal.
- Position the assembled sill between the doorframe and mark fixing points through countersunk holes. Remove sill, drill fixing holes and insert plugs.
- Apply sealing compound to underside groove at front of sill and around kwikfit lugs. Ensure rubber seal at rear is in place and screw sill into place.
Manufacturer | EXITEX |
---|---|
Colour | Silver |
Pack Size | 1 |
Colour | Silver |
